Desciption
Yokogawa ANT10U-415 Unit for Optical ESB Bus Repeater Module
Module Configurations
Power Supply Module (PW481, PW482, or PW484): Two modules in case of a dual-redundant configuration.
Power supply to the I/O modules, and supply power to the transmitters.
The power supply terminals use M4 screws.
Optical ESB Bus Repeater Master Module for 5 km (ANT401): Two modules in case of a dual-redundant configuration.
Optical ESB Bus Repeater Master Module for 5 km to 50 km (ANT411) : Two modules in case of a dual-redundant configuration.
Optical ESB Bus Repeater Slave Module for 5 km (ANT502): Two modules in case of a dual-redundant configuration.
Optical ESB Bus Repeater Slave Module for 5 km to 50 km (ANT512): Two modules in case of a dual-redundant configuration.
